Carriages and Carriage Parts - Rated by the fork carriage hoisting capability, there are actually four sizings of hook type blade carriages. The hook type tine carriages have been standardized.
The carriage bar spacing for Class 1 is about 13 inches and the Class 1 carriage is rated to carry cargo up to 2000lbs. The Class 2 carriage is rated to hold loads up to 5,500lbs with carriage bar spacing of sixteen inches. Class III carriages are rated for cargo as much as 10,000 lbs. The carriage bar spacing for this class is 20 inches. Class IV carriages are rated for cargo up to 15,500 lbs. The carriage bar spacing utilized for this capacity is twenty five inches.
The carriages for pin type blades can be different depending on the manufacturer. Pin mounted tines could differ by the amount of offset between the fork eye and the fork. Carriage capacity will be determined by the carriage pin size and by the blade size.
