Forklift Pinion

Forklift Pinion - The main axis, known as the king pin, is seen in the steering device of a forklift. The first design was a steel pin which the movable steerable wheel was mounted to the suspension. Because it could freely rotate on a single axis, it restricted the degrees of freedom of movement of the remainder of the front suspension. During the 1950s, when its bearings were substituted by ball joints, more detailed suspension designs became available to designers. King pin suspensions are still featured on some heavy trucks for the reason that they have the advantage of being capable of carrying much heavier cargo.

New designs no longer restrict this particular apparatus to moving similar to a pin and nowadays, the term may not be used for an actual pin but for the axis in the vicinity of which the steered wheels turn.

The kingpin inclination or KPI is likewise called the steering axis inclination or likewise known as SAI. This is the description of having the kingpin placed at an angle relative to the true vertical line on most recent designs, as looked at from the front or back of the forklift. This has a major impact on the steering, making it likely to return to the centre or straight ahead position. The centre location is where the wheel is at its uppermost point relative to the suspended body of the lift truck. The vehicles' weight tends to turn the king pin to this position.

Another impact of the kingpin inclination is to set the scrub radius of the steered wheel. The scrub radius is the offset between the projected axis of the steering down through the kingpin and the tire's contact point with the road surface. If these points coincide, the scrub radius is defined as zero. Even though a zero scrub radius is likely without an inclined king pin, it requires a deeply dished wheel so as to maintain that the king pin is at the centerline of the wheel. It is a lot more sensible to incline the king pin and make use of a less dished wheel. This also supplies the self-centering effect.
