Forklift Throttle Body
Forklift Throttle Body - Where fuel injected engines are concerned, the throttle body is the component of the air intake system that regulates the amount of air that flows into the motor. This mechanism works in response to driver accelerator pedal input in the main. Normally, the throttle body is situated between the intake manifold and the air filter box. It is often fixed to or situated next to the mass airflow sensor. The biggest piece in the throttle body is a butterfly valve referred to as the throttle plate. The throttle plate's main task is to be able to control air flow.
On the majority of automobiles, the accelerator pedal motion is transferred through the throttle cable, hence activating the throttle linkages works to be able to move the throttle plate. In cars with electronic throttle control, likewise called "drive-by-wire" an electric motor controls the throttle linkages. The accelerator pedal connects to a sensor and not to the throttle body. This sensor sends the pedal position to the ECU or likewise known as Engine Control Unit. The ECU is responsible for determining the throttle opening based on accelerator pedal position together with inputs from various engine sensors. The throttle body has a throttle position sensor. The throttle cable connects to the black part on the left hand side that is curved in design. The copper coil located near this is what returns the throttle body to its idle position when the pedal is released.
Throttle plates rotate within the throttle body each time pressure is applied on the accelerator. The throttle passage is then opened so as to permit much more air to flow into the intake manifold. Normally, an airflow sensor measures this change and communicates with the ECU. In response, the Engine Control Unit then increases the amount of fluid being sent to the fuel injectors to be able to produce the desired air-fuel ratio. Often a throttle position sensor or likewise called TPS is attached to the shaft of the throttle plate to provide the ECU with information on whether the throttle is in the idle position, the wide-open position or also called "WOT" position or somewhere in between these two extremes.
In order to regulate the minimum air flow while idling, some throttle bodies can include valves and adjustments. Even in units which are not "drive-by-wire" there would usually be a small electric motor driven valve, the Idle Air Control Valve or likewise called IACV which the ECU uses to regulate the amount of air that can bypass the main throttle opening.
In various vehicles it is common for them to have a single throttle body. In order to improve throttle response, more than one could be used and attached together by linkages. High performance automobiles like the BMW M1, along with high performance motorcycles like the Suzuki Hayabusa have a separate throttle body for every cylinder. These models are called ITBs or otherwise known as "individual throttle bodies."
The throttle body and the carburator in a non-injected engine are rather the same. The carburator combines the functionality of both the fuel injectors and the throttle body into one. They could regulate the amount of air flow and mix the air and fuel together. Automobiles which have throttle body injection, which is referred to as CFI by Ford and TBI by GM, locate the fuel injectors inside the throttle body. This permits an older engine the possibility to be converted from carburetor to fuel injection without significantly altering the engine design.
